Leica ASP300

→

↓

Printing run logs

Printing is possible when the PRINT symbol is displayed.

For the PRINT symbol to be displayed, a printer must have been

configured for the instrument.

The following lists and protocols can be printed:

• reagent list,

• stations list,

• reagent status list,

• all programs,

• run log,

• error log.

5.7 Configuring a printer (optional)

To select and configure a printer, proceed as follows:

• With a Centronics standard cable, connect the printer to

the printer port (refer chapter 4.4, Fig. 6).

5. Operation
